China Cheap price Ats Waterproof For Telecom Site – Solar Power Supply 48VDC SHW48500 Outdoor Solar Power System for Telecom Station – Soro Detail:

Overview

Quick Details

Place of Origin:	Guangdong, China	Output Current:	50-500A
Brand Name:	SOROTEC	Input Voltage:	220VAC
Model Number:	SHW48500	Output Voltage:	48VDC
Application:	Industrial	Built-in MPPT:	3000W /50A
Specification:	Normal	Operating Temperatur:	- 20℃ to 55℃
Model:	SHW48500 Solar DC Power System	Overload Protection:	>110% Audible Alarm
Battery Voltage:	48VDC	Output Voltage (V):	48V

Supply Ability

Supply Ability:5000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details：Carton, export type packing or according to your requirement Port：Shenzhen

Solar Power Supply 48VDC SHW48500 Solar DC Power Systems with Dust-proof Function

Application

Power plant or substation power for controlling, protection and automatic device, emergency lighting, communications, steam turbine DC oil pump and so on independent DC systems. It can provide reliable power supply in the case of a power failure completely in plant or substation. The traditional DC systems connect battery pack and run with float charging mode. The new DC system run with silicon controlled rectifying power supply for battery.

Key Features:

1.Adopt advanced MCU microprocessor control technology
2.Advanced MPPT Technology.High converting efficiency higher than 97% for
minimizing energy loss.
3.Reversed current protection at night.over voltage and reverse polarity protection
4.Capable of selection different charging mode fo various types of batteries
5.Protection degree:IP55
6.Industy-leading power density compact size and high reliability
7.Doorframe designed with waterproof structure, posted on the seal and equipped with wateerproof lock in the door double insulation design
8.Cabine adopt quality galvanized wheet or aluminum coated steel sheet as material, surfce coating anti-UV power
9.Suitable for outdoor installation
10.With remote monitoring system aperation

Fine dust-proof, water-proof features
According to the overall standard of design dust-proof and water-proof Ip55

1.With sun protection, heat insulation, roof ventilation

2.With waterproof and the filtration dust inlet, the cabinet front door shutters.

Product Descriptions of Solar DC Power System

SHW48500 Solar System	Rectifier Module(1-10) MPPT Solar Charge Controller(1-10)
INPUT
MPPT Range @Operating Voltage	60 ~150VDC
Maximum PV Array Power	3000W
Maximum Input Current	62A
OUTPUT
Nominal Battery Voltage	42-58VDC
Maximum Charge Current	50A(max:61A)
Maximum Efficiency	98%
Charging Method	Three stages: bulk, absorption and floating
PROTECTION
Overload Protection	> 110% : audible alarm
Overcharge Protection	Yes
Polarity Reversal Protection @Solar Cell & Battery	Yes
INDICATORS
LCD Panel	LCD panel indicating solar power, load level, battery voltage/capacity, charging current, and fault conditions
LED Display	Three indicators for solar, charging, and load status
Rectifier Module
Rated input voltage	220V
AC input Voltage range AC	90-290V
input Frequency range	45-65HZ
Power factor	≥0.99
Efficiency	>92%
Rated output voltage	48V
Rated output current	0-50A
Voltage range	42-58V
WIND CONTROLLER:
Input Power	1KW/2KW
Input Voltage	150-300VAC
Output Voltage	48VDC
Ouput Current	30A/50A
ENVIRONMENT
Humidity	0 ~ 100% RH (No condensing)
Operating Temperature	-20°C to 55°C
Storage Temperature	-40°C to 75°C
Altitude	0 ~ 3000 m

Product detail pictures:
